VaLO - wireless control of lighting gives you more options to operate your luminaires. You can control your LED lighting either with wall-mounted, wireless buttons or with your Android/iOS device such as a tablet or phone. You can control the lighting in your entire home wirelessly if you want, but you can also control individual luminaires.
VaLO wireless lighting control also works particularly well where traditional wired pre-wired wall outlets are not sufficient, or are poorly positioned in relation to the location of the LED lights. With VaLO control, you can turn on, turn off and dim the LED lights continuously. VaLO can also be used to control luminaires with colour temperature or colour control (CCT and RGB), with dedicated buttons and receivers, which you can find on our product page.
Example installation of wireless control
For example, if you wanted to control the kitchen LED strips wirelessly, so that the top strip and the bottom strip light up at different times, your set could be like this (e.g. 2,5m wide kitchen): - 14,4W glowing led strip, 5m roll (cut off so that 2,5m above the cabinetry and 2,5m below the cabinetry) - 90W 24V transformer, non dimmable - VaLO series 2-piece push button, one button to control the dimming of the top strip and one button to control the dimming of the bottom strip - two receivers (12V-36V), one for each button to light them at different times So you need two receivers to light the top and bottom LED strips at different times. In this option the installation goes like this: the transformer is connected to the mains (230V) with a plug, from the transformer you branch the power to receivers A and B. From receiver A the wires go to led strip X and from receiver B the wires go to led strip Y. Once the connection is made, pair buttons 1 and 2 on the switch with receivers A and B. For example button 1 with A and button 2 with B, so that button 1 controls tape X and button 2 controls tape Y.
