VaLO — LED receiver with PUSHDIM for 12V-36V led strips and panels CCT/RGB, 20A
In stock at 16 pcs
SKU#: VaLO-V1236-20A-PUSH
0 / 5 (0)
VaLO series receiver 12V-36V for led strips and panels (RGB/WRGB/CCT strips). Maximum load 4x5A. Button to be ordered separately. Also PUSHDIM (0V) control.
Read more
€ 99.00
VAT 0% | 24%
Add a comment to the order
Delivery methods
Free shipping for orders over to %s
Payment Methods
Pay safely with Credit/Debit Cards, Paypal and others.
Easy returns
Right of return for 14 days
VaLO series receiver 12V-36V for led strips and panels. Allows colour adjustment and dimming of RGB and CCT products. Maximum load 4x5A, max. 4x60W 12V led strip or max. 4x120W 24V led strip or the same number of panel lights. In addition to the receiver, you will need either a wireless button or a WIFI-RF box and an Android/iOS device to control the strip. One receiver can be controlled by more than one button (e.g. when you need control of the top and bottom of the stairs).
The receiver is mounted between the transformer and the LED strip/panel, i.e. control is from the secondary side. So the transformer does not need to be dimmable!
The receiver can also be controlled by a PUSHDIM button (0V), so you can make it a dimmer for a heavy load with the button.
This receiver allows RGB, WRGB and CCT strip and panel colour adjustment in addition to dimming. To adjust colors, order either a wireless rotary dimmer or a WIFI RF box (control from your Android/iOS device).
Contact us or stop by if you need help with product selection. We're happy to help with any questions you may have about controlling and dimming your LED lighting.
- Delivery status In Stock
- Brand Ledstore
- Breadcrumbs Home Lighting controlVaLO RF Wireless controlVaLO RF 12-36V receivers VaLO — LED receiver with PUSHDIM for 12V-36V led strips and panels CCT/RGB, 20A
- Category VaLO RF 12-36V receivers
- SKU VaLO-V1236-20A-PUSH
- Wattage 480
- Voltage (V) 12, 24, 36
- Immennys 12V, 24V, 36V, Dimmable, Wireless VaLO dimming, Wireless dimming, PUSH-DIM
- Light control 176, 175, 234
- Size 180x46x30mm
- Length of the package 6
- Height of the package 3.5
- Width of the package 18
- Change 12V-36V
- Approval CE, RoHS
New product review
Be the first to write a review!
By rating you will be entered into a prize draw for a €50 gift voucher.
Customer questions
No questions yet.
WHAT IS CRI, THE COLOUR RENDERING INDEX
High quality LED lights also have a high colour rendering index, or CRI. A good colour rendering index (CRI) for home use is above 90, and nowadays many market lights are unfortunately closer to 80.
CRI tells you how well an LED light displays colours as they should be. For designers and architects, as well as interior designers, it should be one of the most important considerations. Make sure the lighting is perfect so that your artwork is what it is meant to be.
Colour rendering index
The colour rendering index is expressed as a number on a scale from zero to 100, where 0 = no colour rendering and 100 = full colour rendering. The colour rendering index of LED lights is also known as Ra, which is measured on a smaller scale than CRI. This Ra value does not include red tones or skin tones, for example, so it is a 'glossed' figure for the true quality of an LED light.
RA value
The Ra value measures the reproduction of colours using eight different reference colours. CRI takes into account the wider (15) wavelength range, including reds and other warm colours.
The Ra value is calculated by cutting the wavelength range, weighting the blue and violet tones, and calculating the weighted average of R numbers 1-8.
Excluded from the Ra value are, for example, the colour rendering of bright reds, yellows and greens, and shades close to skin tone. These are described by R-values between 9 and 15. The following is a picture of a measurement result that easily confuses the consumer.
This measurement is from a 9W CCT Led spot
Read more on this topic:
Colour rendering of LEDs - What is the difference between CRI and Ra-value?
