Indoor LED wall light fixture — ECLIPSE 30cm, CCT 3000-6000K 24V, White
ECLIPSE 30cm (white) is an indoor wall lamp for creating your own art. ECLIPSE 30 is a very simple and elegant luminaire. The luminaire provides light indirectly through the wall, making it particularly suitable for atmospheric spaces such as bedrooms, living rooms and staircases.
The light output is 15W which is equivalent to +50W halogen, i.e. 500 lumens. The light shade is standard adjustable in 3 positions 3000/4000/6000K, by supplying the luminaire with 24V. The luminaire does not come with a transformer!
LED wall lamp ECLIPSE 30cm
The perfect choice for modern interiors, offering adjustable and indirect light.
Eclipse 30cm LED wall light combines elegance and functionality. The adjustable colour temperature (3000-6000K) allows you to adjust the light according to your mood.
Features and suitability
Eclipse 30cm is designed to add both light and visual interest to a space. High quality LED technology ensures that the luminaire is not only efficient but also energy efficient.
Technical specifications
The luminaire produces 1200 lumens of light output. The compact and streamlined design integrates seamlessly into contemporary interiors. The light shade is standard adjustable in 3 positions 3000/4000/6000K when using a 24V base transformer. The transformer is not included!
Applications
Eclipse 30cm offers versatility and elegance, suitable for both domestic and public environments. You can create beautiful ensembles by combining Eclipse 30cm and Eclipse 15cm luminaires.
Home
The perfect choice for mood lighting in bedrooms, living rooms, staircases or hallways.
Offices
Create cosy office spaces with Eclipse luminaires.
Public spaces
Ideal for hotels, restaurants and other public spaces where creating atmosphere is important.
Why choose this product?
- Versatile colour temperature control
- Easy operation and wireless control
- Energy efficient LED technology
- Stylish and minimalist design
- Long life and low running costs
Installation
Fix the luminaire to the wall using the supplied fixing accessories, connect the luminaire to the mains and adjust the colour temperature to your preference using the control panel.
We recommend to use this luminaire with a Continuously Variable Temperature (CCT) control from 3000-6000K by connecting all the luminaires to the same transformer in parallel. This allows you to dim and adjust the mood continuously and wirelessly. The product images show a couple of examples of installation. In this case, the wire of the switch box of the luminaire is cut and the 3 wires are stripped out: + (red) and -warm (white), -cold (black).
Example:
- 2 pieces ECLIPSE 15cm
- 2 pieces ECLIPSE 30cm
- 100W 24V Zigbee transformer
- Wireless Zigbee CCT button
NOTE! Transformer to be purchased separately.
Read more about installation in our blog!
- Delivery status In Stock
- Brand Ledstore
- Breadcrumbs Home Led Lights Indoor LED wall light fixture — ECLIPSE 30cm, CCT 3000-6000K 24V, White
- Category Led Lights
- SKU Eclipse-30-W
- 15
- 700
- Interior, Exterior
- White
-
Installation
Driver is separate. Light has switch inside installation box for direct 24V installation. For free CCT adjust cut connector box and strip 3 wires. + and two negatives (warm and cold) and install all lights paraller to driver. First attach the back plate to the wall, then connect wires and lastly install the light to the back plate. This light has a 3 year guarantee.
Size
Diameter 300mm
Depth 50mmCE and RoHS certified
- 24
- 24V, Dimmable
- 3000
- 176
- Life span 35000
- Eclipse-30-W
- 50x150mm
- 30
- 15
- 30
- No driver inside! Sold separate.
- CE, RoHS
Be the first to write a review!
By rating you will be entered into a prize draw for a €50 gift voucher.
WHAT IS CRI, THE COLOUR RENDERING INDEX
High quality LED lights also have a high colour rendering index, or CRI. A good colour rendering index (CRI) for home use is above 90, and nowadays many market lights are unfortunately closer to 80.
CRI tells you how well an LED light displays colours as they should be. For designers and architects, as well as interior designers, it should be one of the most important considerations. Make sure the lighting is perfect so that your artwork is what it is meant to be.
Colour rendering index
The colour rendering index is expressed as a number on a scale from zero to 100, where 0 = no colour rendering and 100 = full colour rendering. The colour rendering index of LED lights is also known as Ra, which is measured on a smaller scale than CRI. This Ra value does not include red tones or skin tones, for example, so it is a 'glossed' figure for the true quality of an LED light.
RA value
The Ra value measures the reproduction of colours using eight different reference colours. CRI takes into account the wider (15) wavelength range, including reds and other warm colours.
The Ra value is calculated by cutting the wavelength range, weighting the blue and violet tones, and calculating the weighted average of R numbers 1-8.
Excluded from the Ra value are, for example, the colour rendering of bright reds, yellows and greens, and shades close to skin tone. These are described by R-values between 9 and 15. The following is a picture of a measurement result that easily confuses the consumer.
This measurement is from a 9W CCT Led spot
Read more on this topic:
Colour rendering of LEDs - What is the difference between CRI and Ra-value?
