VaLO Zigbee LED receiver 12-24V - for two-wire CCT led strips 5A

VaLO Zigbee dimmable receiver for two wire CCT LED strips

LedStore's Zigbee wireless dimming receiver for 12-24V two wire CCT strip lights. Max. load 60-120W (5A).

The controller is mounted between the transformer and the luminaire and the controller passes through the voltage that is fed to it, e.g. voltage 24V from the transformer in and 24V to the two wire CCT strip out, i.e. control is from the secondary side. So the transformer does not have to be dimmable!

In addition to the receiver, you need either a wireless CCT Zigbee button or a WIFI Zigbee box and an Android/iOS device to control the tape. One receiver can be controlled by more than one button (e.g. when you need control from the top and bottom of the stairs).

Zigbee note: It only allows you to pair ONE button directly per transformer. If you want multiple buttons on the same transformer (e.g. staircase switching) you need to have a HUB and an Android/Ios app. All devices are paired to the HUB and there it is determined what they do.

This receiver allows CCT color temperature control of two wire LED strips in addition to dimming.

Contact us or stop by if you need help with product selection. We are happy to help with any questions you may have about LED lighting control and dimming.

For control:

Zigbee smart control can be enabled by selecting LedStore's Zigbee hub and downloading the Azoula Smart app for Android or iOS as an interface. LedStore's Zigbee devices also work with other hubs and their interfaces.
If you need wireless control of your luminaires without timers or smart controls, or if you need to add other sensing devices or mobile control (mobile phone or tablet), a Zigbee receiver and a button controller/regulator are sufficient. Ask us for more information!

Is VaLO Zigbee compatible with other Zigbee devices?

Yes! If you have a Philips Hue controller, for example, you can use it for example:

IKEA TRÅDFRI system, Google Home devices and software and of course any other Zigbee product.

Zigbee pairing?

We've gone through the pairings in blog articles, you can find them by name:

• zigbee-lighting-control-home-part-1, where we go through how to pair without a hub/bridge
• zigbee-lighting-control-haltuun-part-2, where we go through pairing with a hub/bridge (Philips Hue and Samsung Smart Things)
• zigbee-lighting-control-haltuun-part-3, which completes the application options, taking into account multiple types of luminaires and sensors.
• cct-zigbee-under-lighting-from-the-installer's-eye-view, discussing Zigbee and CCT lighting from an installer's perspective
• zigbee-part-5-pairing-with-connectivity-only, with a comprehensive overview of the different deployment options with or without a hub.

What the heck is Zigbee?

Zigbee is a wireless RF system using MESH technology, where each device is both a receiver and a transmitter, ensuring that commands get through even in larger locations. Zigbee devices can be freely interconnected between different manufacturers. This device supports the latest ZIGBEE 3.0 protocol.

With LedStore's VaLO Zigbee wireless lighting control, you can control your lighting either with wall-mounted wireless buttons or with your Android/iOS device such as a tablet or phone. You can control the lighting of your entire home wirelessly if you wish, but you can also control individual lights.
Zigbee is the only complete IoT (Internet of Things) solution - from a mesh network to a universal standard that allows smart devices to talk to each other. Thanks to the dedicated mesh network created by the devices, the message always reaches its destination, as each device is a receiver and a transmitter.

Zigbee is a standardised system to which you can connect any device in the Zigbee alliance and the certified product will seamlessly communicate with other devices connected to the network. The alliance includes Google, Apple, IKEA, Amazon, Panasonic and Somfy.
Zigbee products are already in millions of homes around the world. Our devices support the latest Zigbee 3.0 standard and are backwards compatible.

Dimensions

Length: 146mm
Width: 47mm
Height: 17mm
