12V dimmable LED DRIVER 100W, TRIAC, for LED strip, IP21
In stock at 29 pcs
SKU#: 12V-100W-IP21-triac
0 / 5 (0)
TRIAC dimmable power supply for 12V LED strip, 100W load capacity. The transformer can be dimmed from both sides with rotary dimmers.
Read more
€ 129.00
VAT 0% | 24%
Add a comment to the order
Delivery methods
Free shipping for orders over to %s
Payment Methods
Pay safely with Credit/Debit Cards, Paypal and others.
Easy returns
Right of return for 14 days
Details
TRIAC dimmable power supply for 12V led strip, 100W load capacity. The power supply has one output, which can be branched to several strips if necessary (no quick connector). The power supply does not have a plug. The transformer can be dimmed from the front side by rotary dimmers such as EXXACT.
You can connect a total of 5,5m HELMEILE 14,4W/m or 11m HELMEILE 7,2W/m led strip to this power supply.
For lengths over 5m, the strip may lose light if only one end of the strip is supplied.
Dimensions
Length: 200mm
Width: 70mm
Height: 47mm
CE, RoHS, SELV, IP21.
- Delivery status In Stock
- Brand Ledstore
- Breadcrumbs Home LED accessoriesLED strip driver12V drivers 12V dimmable LED DRIVER 100W, TRIAC, for LED strip, IP21
- Category 12V drivers
- SKU 12V-100W-IP21-triac
- Wattage 100
- Model 12V driver 100Wtriac
- Size 47x200x70mm
- Length of the package 8
- Height of the package 5.5
- Width of the package 25
- Approval CE, RoHS, IP21, SELV
New product review
Be the first to write a review!
By rating you will be entered into a prize draw for a €50 gift voucher.
Customer questions
- How long is the connecting wire between the 12V or 24V transformer and the luminaire?
- Where to place the transformer?
- How to calculate the transformer size? What does 100W mean in practice?
- Can I install several different led strips on the same transformer?
- What is the difference between a 12V and a 24V transformer?
- What happens if I put a 12V led strip into a 24V transformer or vice versa?
- How long can I put a 12 or 24V transformer before the lamp?
- What is a TRIAC dimmable transformer?
- What can be used to dim TRIAC dimmable transformers?
- What is an ampere? Watt? Power?
WHAT IS CRI, THE COLOUR RENDERING INDEX
High quality LED lights also have a high colour rendering index, or CRI. A good colour rendering index (CRI) for home use is above 90, and nowadays many market lights are unfortunately closer to 80.
CRI tells you how well an LED light displays colours as they should be. For designers and architects, as well as interior designers, it should be one of the most important considerations. Make sure the lighting is perfect so that your artwork is what it is meant to be.
Colour rendering index
The colour rendering index is expressed as a number on a scale from zero to 100, where 0 = no colour rendering and 100 = full colour rendering. The colour rendering index of LED lights is also known as Ra, which is measured on a smaller scale than CRI. This Ra value does not include red tones or skin tones, for example, so it is a 'glossed' figure for the true quality of an LED light.
RA value
The Ra value measures the reproduction of colours using eight different reference colours. CRI takes into account the wider (15) wavelength range, including reds and other warm colours.
The Ra value is calculated by cutting the wavelength range, weighting the blue and violet tones, and calculating the weighted average of R numbers 1-8.
Excluded from the Ra value are, for example, the colour rendering of bright reds, yellows and greens, and shades close to skin tone. These are described by R-values between 9 and 15. The following is a picture of a measurement result that easily confuses the consumer.
This measurement is from a 9W CCT Led spot
Read more on this topic:
Colour rendering of LEDs - What is the difference between CRI and Ra-value?
